Below are optional Quorum accessories which have been designed and engineered to complement this specific fan.

Material 1: Steel
Material 2: Copper
Material 3: Aluminum
~
Finish 1: Studio White
~
Height (inch): 8.25
Diameter (inch): 54
Weight (lbs): 13.8
~
Motor Housing Diameter (inch): 4.92
~
Number of Blades: 3
Blade Finish A: Studio White
Blade Finish B: Satin Opal
Blade Material: ABS
Blade Pitch: 14°
~
UL Type: Damp

Remote Adaptable: Yes
Smart By Bond Included: No
Switch Type: 6 speed wall control
Reverse Switch Type: Wall control
~
EnergyGuide Airflow Efficiency: 317
EnergyGuide CFM: 3995
EnergyGuide Sweep (Inch): 54
EnergyGuide Watts: 13
~
Watts: 16/11/7/5/3/2
RPM: 165/147/127/101/73/52
CFM High Speed 1: 6088
CFM/Watts High Speed: 320
Watts High Speed 1: 19
Amps: .22/.16/.11/.07/.06/.05
~
Motor Size: DC-125NS
Motor Poles: 8
Motor Warranty: Limited Lifetime Motor Warranty
~

Light Kit Included: Yes
Light Kit Adaptable: No
Number of Lights: 1
Integrated LED: Yes
Socket Base: LED Array
Color Temperature: 3000K
Initial Lumens: 1116
CRI: 90


~
Downrod Length 1 (inch): 4
Downrod Diameter 1 (inch): .5
Downrod Length 2 (inch): 6
Dowrod Diameter 2 (inch): .5
~
Ceiling to Blade 1 (inch): 10.25
Ceiling to Bottom 1 (inch): 12.25
Ceiling to Blade 2 (inch): 12.25
Ceiling to Bottom 2 (inch): 14.25
~
Sloped Ceiling Adaptable: Yes
~
Canopy Height (inch): 2.25
Canopy Finish: Studio White
~
Lead Wire Length (inch): 80

Safety Ratings: cUL

Note: 18W LED Light Kit Included

Shipping Via: Parcel
Carton Height (inch): 7.25
Carton Length (inch): 28.75
Carton Width (inch): 14.5

Cutsheet PDF
