Below are optional Quorum accessories which have been designed and engineered to complement this specific fan.

Material 1: Steel
Material 2: Zinc
Material 3: Wood
~
Finish: Oiled Bronze
~
Width (inch): 52
Height (inch): 10.25
Diameter (inch): 52
Weight (lbs): 19
~
Motor Housing Diameter (inch): 10.75
Motor Housing Height (inch): 2.32
Motor Housing Mesh Color: Oiled Bronze
~
Number of Blades: 5
Blade Finish A: Dark Oak
Blade Material: MDF
Blade Pitch: 12°
~
UL Type: Dry

Remote Adaptable: Yes
Smart By Bond Included: Yes
Switch Type: 3 speed pull chain
Reverse Switch Type: Manual Reverse Switch
~
EnergyGuide Airflow Efficiency: 91
EnergyGuide CFM: 4041
EnergyGuide Sweep (Inch): 52
EnergyGuide Watts: 44
~
Watts: 66/33/10
RPM: 173/122/64
CFM High Speed 1: 4449
CFM/Watts High Speed: 70
Watts High Speed 1: 58
Amps: .55/.39/.22
~
Motor Size: AC-153x15
Motor Poles: 14
Motor Height (mm): 15Motor Width (mm): 153
Motor Warranty: Limited Lifetime Motor Warranty
~

Light Kit Included: Yes
Light Kit Adaptable: No
Number of Lights: 2
Socket Base: Medium
Color Temperature: 3000K
Initial Lumens: 1600
CRI: 80


Hugger Adaptable: Yes
~
Downrod Length 1 (inch): 3.5
Downrod Diameter 1 (inch): .5
Downrod Length 2 (inch): 6
Dowrod Diameter 2 (inch): .5
~
Ceiling to Blade 1 (inch): 9.75
Ceiling to Bottom 1 (inch): 16.5
Ceiling to Blade 2 (inch): 12.25
Ceiling to Bottom 2 (inch): 19
~
Sloped Ceiling Adaptable: Yes
~
Canopy Height (inch): 2.25
Canopy Finish: Oiled Bronze
~
Lead Wire Length (inch): 80

Safety Ratings: cUL

Note: Detachable Switch Cup | Triple Capacitor | Skirted Blade Arms

Shipping Via: Parcel
Carton Height (inch): 10.75
Carton Length (inch): 24.5
Carton Width (inch): 13
