Below are optional Quorum accessories which have been designed and engineered to complement this specific fan.

Material 1: Steel
Material 2: Zinc
Material 3: Wood
~
Finish: Textured Black
~
Width (inch): 52
Height (inch): 9.65
Diameter (inch): 52
Weight (lbs): 16.8
~
Motor Housing Diameter (inch): 10.75
Motor Housing Height (inch): 2.32
Motor Housing Mesh Color: Textured Black
~
Number of Blades: 5
Blade Finish A: Matte Black
Blade Finish B: Weathered Oak
Blade Material: MDF
Blade Pitch: 12°
~
UL Type: Dry

Remote Adaptable: Yes
Smart By Bond Included: Yes
Switch Type: 3 speed pull chain
Reverse Switch Type: Manual Reverse Switch
~
EnergyGuide Airflow Efficiency: 87
EnergyGuide CFM: 3144
EnergyGuide Sweep (Inch): 52
EnergyGuide Watts: 36
~
Watts: 66/33/10
RPM: 173/122/64
CFM High Speed 1: 4449
CFM/Watts High Speed: 77
Watts High Speed 1: 58
Amps: .55/.39/.22
~
Motor Size: AC-153x15
Motor Poles: 14
Motor Height (mm): 15Motor Width (mm): 153
Motor Warranty: Limited Lifetime Motor Warranty
~

Light Kit Included: No
Light Kit Adaptable: Yes


Hugger Adaptable: Yes
~
Downrod Length 1 (inch): 3.5
Downrod Diameter 1 (inch): .5
Downrod Length 2 (inch): 6
Dowrod Diameter 2 (inch): .5
~
Ceiling to Blade 1 (inch): 9.75
Ceiling to Bottom 1 (inch): 11.75
Ceiling to Blade 2 (inch): 12.25
Ceiling to Bottom 2 (inch): 14.25
~
Sloped Ceiling Adaptable: Yes
Sloped Ceiling Compatibility: 25
Extended Sloped Ceiling Compatibility: 45
~
Canopy Height (inch): 2.25
Canopy Finish: Textured Black
~
Lead Wire Length (inch): 80

Safety Ratings: cUL

Note: Detachable Switch Cup | Triple Capacitor | Skirted Blade Arms

Shipping Via: Parcel
Carton Height (inch): 10.75
Carton Length (inch): 22.5
Carton Width (inch): 13

Cutsheet PDF
Instructions PDF
