Material 1: Aluminum
Material 2: Iron
Material 3: Steel
~
Height (inch): 8.75
Diameter (inch): 56
Weight (lbs): 19
~
Motor Housing Diameter (inch): 7.09
~
Number of Blades: 5
Blade Finish A: Studio White
Blade Material: Plastic
Blade Pitch: 16°
~
UL Type: Dry

Remote Adaptable: No
Smart by Bond Included: No
Switch Type: 6 speed wall control
Reverse Switch Type: Wall Control
~
EnergyGuide Airflow Efficiency: 202
EnergyGuide CFM: 4186
EnergyGuide Sweep (Inch): 56
EnergyGuide Watts: 21
~
Watts: 24/19/12/9/6/4
RPM: 178/164/141/121/100/83
CFM High Speed 1: 5560
CFM/Watts High Speed: 179
Watts High Speed 1: 31
Amps: .25/.23/.21/.15/.10/.07
~
Motor Size: 120DCx25
Motor Poles: 8
Motor Width (mm): 120
Motor Warranty: Limited Lifetime Motor Warranty
~

Light Kit Included: Yes
Light Kit Adaptable: No
Number of Lights: 1
Integrated LED: Yes
Socket Base: LED Array
Color Temperature: 3000K
Initial Lumens: 986
CRI: 90


~
Downrod Length (inch): 4.5
Downrod Diameter (inch): .5
~
Ceiling to Blade (inch): 10.75
Ceiling to Bottom (inch): 13.5
~
Sloped Ceiling Adaptable: No
~
Canopy Width (inch): 5.75
Canopy Height (inch): 2.25
Canopy Finish: Studio White
~
Lead Wire Length (inch): 80

Note: 6 Speed Wall Control Included | LED Light Kit is 15W, 3000k, 986 Lumens, 90CRI (dimmable)

Shipping Via: Parcel
Carton Height (inch): 9.75
Carton Length (inch): 20.5
Carton Width (inch): 13
