Material 1: Iron
Material 2: Steel
Material 3: Zinc
Finish 1: Aged Brass
Height (inch): 9.25
Diameter (inch): 52
Weight (lbs): 19
Motor Size: 172x14
Motor Poles: 16
Motor Height (mm): 14
Motor Housing Diameter (inch): 10.32
Motor Housing Height (inch): 2.28

Number of Blades: 5
Blade Finish A: Walnut
Blade Finish B: Weathered Oak
Blade Material: Plywood
Blade Pitch: 13.5°

UL Type: Dry

Light Kit Included: No
Light Kit Adaptable: Yes

Amps: .51/.36/.20

Hugger Adaptable: Yes

Downrod Length 1 (inch): 4
Downrod Diameter 1 (inch): .5
Downrod Length 2 (inch): 6
Dowrod Diameter 2 (inch): .5

Ceiling to Blade 1 (inch): 11
Ceiling to Bottom 1 (inch): 13.25
Ceiling to Blade 2 (inch): 13
Ceiling to Bottom 2 (inch): 15.25

Sloped Ceiling Adaptable: No

Canopy Width (inch): 5.25
Canopy Height (inch): 2.25
Canopy Finish: Aged Brass

Lead Wire Length (inch): 80

Remote Adaptable: Yes
Smart by Bond Included: Yes

Switch Type: 3 speed pull chain
Reverse Switch Type: Manual Reverse Switch

EnergyGuide Airflow Efficiency: 81

EnergyGuide CFM: 3289

EnergyGuide Sweep (Inch): 52

EnergyGuide Watts: 41

Watts: 64/33/8
RPM: 160/110/62
CFM High Speed 1: 4446

CFM/Watts High Speed: 69

Watts High Speed 1: 64

Motor Size: 172x14

Motor Height (mm): 14Motor Width (mm): 172

Motor Poles: 16

Motor Warranty: Limited Lifetime Motor Warranty

Note: Detachable Switch Cup | Skirted Blade Arms

Shipping Via: Parcel

Carton Height (inch): 13
Carton Length (inch): 11.25
Carton Width (inch): 21.25

Cutsheet PDF
