Material 1: Steel
Material 2: Glass
Material 3:
~
Finish: Brushed Brass
~
Width (inch): 7
Height (inch): 6.5"
Extension (inch): 9.25"
Weight (lbs): 4.8
~
Diffuser Material: Glass
Diffuser Height: 3.5
Diffuser Width: 7
~
UL Type: Damp
~

~
Dimming: TRIAC
~

~
Number of Lights: 1
Integrated LED: Yes
Socket Base: LED Array
~
Color Temperature: 5 CCT
CCT 1: 2700
CCT 2: 3000
CCT 3: 4000
CCT 4: 5000
CCT 5: 6500
~
Initial Lumens: 836
Delivered Lumens: 338.3
CRI: 90
Watts: 9
~
Driver Model: NE016277YYY-2GH
Driver Voltage: 120-277V
~

~
Back Plate Width (inch): 5.13
Back Plate Height (inch): 5.13
Back Plate Depth (inch): 1.18
~
Mounting to Top of Fixture(inch): 0.67
~
Mounting to Bottom of Back Plate(inch): 3.15
Mounting Plate Height (inch): 1.18
Mounting Plate Width (inch): 4.8
Mounting to Top of Back Plate(inch): 1.96
LED Lifespan Hours: 50,000
22.44
~

Shipping Via: Parcel
Carton Weight (lbs): 6.2
Carton Height (inch):7.48"
Carton Length (inch):22.44"
Carton Width (inch): 9.45"
