Below are optional Quorum accessories which have been designed and engineered to complement this specific fan.

Material 1: Steel
Material 2: Zinc
Material 3: Wood
~
Finish: Oiled Bronze
~
Width (inch): 60
Diameter (inch): 60
Weight (lbs): 22
~
Motor Housing Diameter (inch): 11.02
Motor Housing Height (inch): 2.75
Motor Housing Mesh Color: Aged Brass
~
Number of Blades: 5
Blade Finish A: Oiled Bronze
Blade Material: Plywood
Blade Pitch: 11°
~
UL Type: Dry

Remote Adaptable: Yes
Smart by Bond Included: Yes
Switch Type: 3 speed pull chain
Reverse Switch Type: Slide
~
EnergyGuide Airflow Efficiency: 78
EnergyGuide CFM: 3964
EnergyGuide Sweep (Inch): 60
EnergyGuide Watts: 51
~
Watts: 74/48/24
RPM: 138/104/66
CFM High Speed 1: 5290
CFM/Watts High Speed: 71
Watts High Speed 1: 74
Amps: .62/.51/.37
~
Motor Size: 188x20
Motor Poles: 16
Motor Height (mm): 20Motor Width (mm): 194
Motor Warranty: Limited Lifetime Motor Warranty
~

Light Kit Included: No
Light Kit Adaptable: Yes
Integrated LED: No


Hugger Adaptable: Yes
~
Downrod Length (inch): 6
Downrod Diameter (inch): .5
~
Ceiling to Blade (inch): 10.25
Ceiling to Bottom 1 (inch): 12.5
Ceiling to Bottom 2 (inch): 10.25
~
Sloped Ceiling Adaptable: Yes
Sloped Ceiling Compatibility: 23
Extended Sloped Ceiling Compatibility: 45
~
Canopy Width (inch): 5.17
Canopy Height (inch): 2.25
Canopy Finish: Oiled Bronze
~
Lead Wire Length (inch): 80

Safety Ratings: cUL

Shipping Via: Parcel
Carton Height (inch): 9.75
Carton Length (inch): 13.25
Carton Width (inch): 12.25

Instructions PDF
