Below are optional Quorum accessories which have been designed and engineered to complement this specific fan.

Material 1: Steel
Material 2: Zinc
Material 3: Wood
~
Finish: Studio White
Finish 2: Studio White
~
Width (inch): 60
Height (inch): 10.25
60
Weight (lbs): 22
~
Motor Housing Diameter (inch): 11.02
Motor Housing Height (inch): 2.75
~
Number of Blades: 5
Blade Finish A: Stuido White
Blade Finish B: Washed Oak
Blade Material: Plywood
Blade Pitch: 11°
~
UL Type: Dry

Remote Adaptable: No
Switch Type: 3 Speed w/ Pull Chain
Reverse Switch Type: Manual Reverse Switch
~
EnergyGuide Airflow Efficiency: 78
EnergyGuide CFM: 3964
EnergyGuide Sweep (Inch): 60
EnergyGuide Watts: 51
~
Watts: 74/48/24
RPM: 138/104/66
CFM/Watts High Speed: 71
Watts High Speed 1: 74
Amps: .62/.51/.37
~
Motor Size: 188 x 20
Motor Poles: 16
Motor Height (mm): 20Motor Width (mm): 188
Motor Warranty: Limited Lifetime Motor Warranty
~

Light Kit Included: No
Light Kit Adaptable: Yes
Integrated LED: No
Socket Base: Medium
Voltage: 120


Hugger Adaptable: Yes
~
Downrod Length (inch): 6
Downrod Diameter (inch): .5
~
Ceiling to Blade (inch): 10.25
Ceiling to Bottom (inch): 12.5
~
Sloped Ceiling Adaptable: Yes
Sloped Ceiling Compatibility: 23
Extended Sloped Ceiling Compatibility: 45
~
Canopy Width (inch): 5.17
Canopy Height (inch): 2
Canopy Finish: Aged Brass
~
Lead Wire Length (inch): 80

Safety Ratings: cUL

Shipping Via: Parcel
22
Carton Height (inch): 10.16
Carton Length (inch): 25.91
Carton Width (inch): 12.84

Cutsheet PDF
Instructions PDF
