Material 1: Steel
Material 2: Zinc
Material 3: Wood
~
Finish: Studio White
~
Width (inch): 52
Diameter (inch): 52
Weight (lbs): 15.6
~
Motor Housing Diameter (inch): 11.02
Motor Housing Height (inch): 2.75
Motor Housing Mesh Color: Studio White
~
Number of Blades: 5
Blade Finish A: Studio White
Blade Material: MDF
Blade Pitch: 12°
~
UL Type: Dry

Remote Adaptable: No
Smart By Bond Included: No
Switch Type: 3 speed pull chain
Reverse Switch Type: Slide
~
EnergyGuide Airflow Efficiency: 81
EnergyGuide CFM: 3352
EnergyGuide Sweep (Inch): 52
EnergyGuide Watts: 41
~
Watts: 66/39/14
RPM: 167/126/75
CFM High Speed 1: 4487
CFM/Watts High Speed: 70
Watts High Speed 1: 64
Amps: .56/.42/.26
~
Motor Size: 153x15
Motor Poles: 14
Motor Height (mm): 13Motor Width (mm): 153
Motor Warranty: Limited Lifetime Motor Warranty
~

Light Kit Included: No
Light Kit Adaptable: No


Hugger Adaptable: Yes
~
Downrod Length (inch): 6
Downrod Diameter (inch): .5
~
Ceiling to Blade (inch): 10.25
Ceiling to Bottom 1 (inch): 15.5
Ceiling to Bottom 2 (inch): 10.25
~
Sloped Ceiling Adaptable: Yes
Sloped Ceiling Compatibility: 23
Extended Sloped Ceiling Compatibility: 45
~
Canopy Width (inch): 5.12
Canopy Height (inch): 2.25
Canopy Finish: Studio White
~
Lead Wire Length (inch): 80

Shipping Via: Parcel
Carton Height (inch): 9
Carton Length (inch): 33
Carton Width (inch): 12.25
