Below are optional Quorum accessories which have been designed and engineered to complement this specific fan.

Material 1: Steel
Material 2: Zinc
Material 3: Wood
~
Finish: Studio White
Finish 2: Studio White
~
Width (inch): 52
Height (inch): 18.25
52
Weight (lbs): 20.6
~
Motor Housing Diameter (inch): 11.02
Motor Housing Height (inch): 2.75
~
Number of Blades: 5
Blade Finish A: Stuido White
Blade Finish B: Washed Oak
Blade Material: Plywood
Blade Pitch: 12°
~
UL Type: Dry

Remote Adaptable: No
Switch Type: 3 Speed w/ Pull Chain
Reverse Switch Type: Manual Reverse Switch
~
EnergyGuide Airflow Efficiency: 81
EnergyGuide CFM: 3352
EnergyGuide Sweep (Inch): 52
EnergyGuide Watts: 41
~
Watts: 66/33/13
RPM: 167/127/72
CFM/Watts High Speed: 70
Watts High Speed 1: 64
Amps: .54/.42/.25
~
Motor Size: 153x13
Motor Poles: 14
Motor Height (mm): 13Motor Width (mm): 153
Motor Warranty: Limited Lifetime Motor Warranty
~

Light Kit Included: Yes
Light Kit Adaptable: No
Number of Lights: 4
Integrated LED: No
Socket Base: Medium
CRI: 80
Voltage: 120


Hugger Adaptable: Yes
~
Downrod Length (inch): 6
Downrod Diameter (inch): .5
~
Ceiling to Blade (inch): 10.25
Ceiling to Bottom (inch): 18.25
~
Sloped Ceiling Adaptable: Yes
Sloped Ceiling Compatibility: 23
Extended Sloped Ceiling Compatibility: 45
~
Canopy Height (inch): 2
Canopy Finish: Aged Brass
~
Lead Wire Length (inch): 80

Safety Ratings: cUL

Shipping Via: Parcel
20.6
Carton Height (inch): 11.02
Carton Length (inch): 23.07
Carton Width (inch): 12.76
